JSOP
Operating Range
| Capaicty |
Up to 650 M3/hr |
| Head |
Up to 56 mtr |
| Discharge Size |
Dn 32 to 200 mm |
| Temperature |
Up to 140°C |
| Speed |
Up to 3500 rpm |
| Pressure |
Up to 5.6 kg/cm2 |
Applications
- Handling pulp stock up to 7% consistency in Pulp & Paper industries.
- Handling Sugar Juice, Bagasse Slurries, Effluent, Water Thin & Thick Sludge in Sugar industries.
- All liquor applications in Pulp & Paper industries.
- Palm oil mills and Refineries, Food industries.
- Waste water treatment plant, Starch industries.
- Salt, Rubber, General industrial services etc.....
Materials
- SS-316, SS-316 L, SS-304, SS-304L
- Duplex stainless steel
- Super duplex stainless steel
- Cast bronze, cast steel, cast Iron
- Hastalloy - B & C, Alloy-20 etc.....
Features
- Single stage open & semi open impeller
- Casing wear plate for protect the volute casing.
- Back pull out design
- Conform to ISO 2858 dimensions
- High efficiency hydraulic design
- Heavy duty shaft, sleeve and bearings
- Low NPSH
- Noise and maintenance free
- Steady head & capacity
- One roller bearing on pump end, two angular contact ball bearing with oil lubricated
- Several flange drilling options according to valid standards.
- Suitable with V-belt drive or direct coupled with a motor.
